AtomOne SSM500 C-Mount

Tech Specs

FeatureDetails
MountC-Mount
ResolutionFull HD 1920 x 1080
Shutter TypeGlobal shutter (1/25 – 1/10,000s)
Sensor Size2/3” CMOS
Sensor Frame Rates50 – 500 fps
Dynamic300 fps 12 bit – 500 fps 10 bit
Progressive Framerates23.98, 24, 25, 29.97, 30, 47.96, 48, 50, 59.94, 60
Interlaced Framerates50i, 59.94i, 60i
Recording Time60 seconds (500fps)
HDRHLG, PQ and SLOG3
Dynamic300 fps 12 bit – 500 fps 10 bit
SensitivityISO 640
ColourMulti matrix support
ControlIP
Video OutputSSM mode (4x3G) or Trigger mode SDI output: 4x 3G output
Genlock InputYes
Lens ControlMotor Drive for IRIS motor
Size60mm x 60mm x 189mm
Weight900g
